>>3147
In the optics business they call that a "choke rangefinder" or "stadiametric rangefinder," among other things. They are actually fairly common IRL in optical sights designed for a certain category of purpose. Not all of them are laid out exactly like that one. There are a wild profusion of designs. This one requires the user to measure objects 50cm across (that is, the width of an average adult male's shoulders) with each of the little horizontal bars going across the center below the center crosshairs. The reticle is designed for a sight that is to be mounted on certain very specific weapons, using certain very specific ammunition. Each of those horizontal bars is at a distance below the center corresponding to the trajectory of a bullet at that specific range. When zeroed at two hundred meters, the crossbars below the center are for three hundred, four hundred, five hundred, and six hundred. The crossbars located elsewhere on the reticle are each five milliradians from the center, which can be used to measure other objects and estimate the distance to them as well.
